HDBaseT Optimal Performance CAT Ethernet Cable Chart

By Gary Jones October 07, 2025 1 min read

Follow HDBaseT guidelines for optimal performance with J-Tech Digital HDMI over Ethernet extenders.

J-Tech Digital is a proud member of the HDBaseT alliance since 2017. Please follow these guidelines provided by HDBaseT for optimal performance with your J-Tech Digital HDMI over Ethernet extenders.

Please note: Stranded cables will reduce performance significantly.
Patch cables, wall plates, connecting blocks may affect transmission distance. Please refer to HDBaseT™ Do’s & Don’ts and Best Practices (http://installers.hdbaset.org/wp-content/uploads/2014/09/Dos-and-Donts-WP.pdf)
While CAT5e can support 4K resolutions, transmission distances are greatly reduced versus using CAT6A or greater.
J-Tech Digital recommends T568A or T568B termination for optimal performance.

Call our team at (888) 610-2818 or email us at sales@jtechdigital.com or support@jtechdigital.com for more information!
