Model: JTECH-VW0109-AE
JTD-ID: JTD-3260
Category: Video Wall Processor Controller
Setup Guide & Configuration Overview
This setup guide explains how to properly connect, configure, and operate the 3×3 HDMI Video Wall Processor, allowing you to combine up to nine displays into a seamless video wall while extracting audio to an external sound system
Product Overview
The 3×3 Video Wall Processor takes a single HDMI source (up to 4K@30Hz) and distributes it across up to nine 1080p displays in multiple video wall layouts. It also features audio extraction, screen rotation, and edge masking to create a clean, professional video wall installation.
Ideal for:
-
Sports bars
-
Digital signage
-
Control rooms
-
Retail displays
-
Corporate lobbies
Key Features
-
4K 3×3 Video Wall Processing.
-
Combine up to 9 HDMI displays into one large canvas
-
Supports 4K@30Hz input and 1080p output per screen
-
13 Video Wall Display Modes
3×3, 2×2, 1×1 (Splitter), 2×4, 2×3, 4×2, 3×2, 1×2, 2×1, 1×3, 3×1, 1×4, 4×1
-
Audio Extraction Function
-
Optical (SPDIF) – up to 5.1ch
-
3.5mm analog – 2ch stereo
-
Image Rotation & Edge Masking
-
Rotate each screen up to 180° (Modes 1–12)
-
Edge masking up to 8 pixels per side to hide bezels
Front & Rear Panel Overview
Key Connections
-
HDMI IN ×1 – Source input (PC, media player, laptop)
-
HDMI OUT ×9 – Display outputs
-
Optical (SPDIF) – Digital audio output
-
3.5mm Stereo – Analog audio output
-
IR Receiver – Remote control
-
Micro-USB – RS-232 / firmware
-
DC 12V – Power input
⚠️ Note: 1×1 Splitter Mode does not support rotation or edge masking
Basic Video Wall Connection Setup
Step-by-Step
-
Connect your HDMI source to the HDMI IN port
-
Connect up to 9 displays to HDMI OUT 1–9
-
Connect your audio system using:
-
Optical SPDIF (5.1ch), or
-
3.5mm analog (2ch)
-
Power the unit using the 12V DC adapter
-
Power on the source and all displays
Selecting Video Wall Display Modes
Use the MODE button on the front panel or remote to toggle between 13 display modes.
Common Layouts
|
Mode |
Layout |
|
Mode 1 |
3×3 |
|
Mode 2 |
2×2 |
|
Mode 3 |
2×3 |
|
Mode 4 |
4×2 |
|
Mode 5 |
3×2 |
|
Mode 6 |
2×2 (dual) |
|
Mode 7 |
1×2 |
|
Mode 8 |
2×1 |
|
Mode 9 |
1×3 |
|
Mode 10 |
3×1 |
|
Mode 11 |
1×4 |
|
Mode 12 |
4×1 |
|
Mode 13 |
1×1 Splitter |
Audio Output Configuration
Audio Outputs
-
Optical SPDIF
-
Supports LPCM, Dolby Digital, DTS (up to 5.1ch)
-
3.5mm Analog
-
Stereo (2ch only)
180° Image Rotation Function
The processor supports independent 180° rotation per output in Modes 1–12.
When to Use Rotation
-
When TVs are installed upside-down
-
To reduce visible bezel gaps
-
For creative video wall layouts
Rotation is not supported in 1×1 splitter mode
Edge Masking (Bezel Compensation)
Edge masking removes visual gaps caused by display bezels.
-
Adjustable ±8 pixels per edge
-
Can be applied individually per output
-
Helps create a seamless image across screens
Supported Specifications (Quick View)
-
HDMI Input: 1× (Up to 4K@30Hz)
-
HDMI Output: 9× (1080p@60Hz)
-
Audio Output: SPDIF ×1, 3.5mm ×1
-
Power: 12V DC / 1A
-
Bandwidth: 3.4Gbps per channel
-
Operating Temp: 0–70°C
