Model: JTECH-WEX4K-100
JTD-ID: JTD-3276
Category: HDMI Extender
Looking to eliminate long HDMI cable runs without sacrificing video quality? The JTD-3276 4K 30Hz Wireless HDMI Extender makes it easy to transmit high-quality video and audio up to 328ft wirelessly, perfect for home theaters, offices, conference rooms, and commercial AV setups.
In this guide, we’ll walk you through everything you need to get up and running quickly.
What’s Included
Inside the box, you’ll find:
- 1 × Wireless HDMI Transmitter (TX)
- 1 × Wireless HDMI Receiver (RX)
- 2 × Power Adapters
- 1 × User Manual
Key Features at a Glance
- Wireless HDMI Transmission (Up to 328ft): Send 4K@30Hz video and audio with no cables required
- Audio Flexibility: Analog audio input (TX) + AUX audio output (RX)
- HDMI Loop-Out: Connect a local display at the transmitter
- IR Control: Control your source device remotely from another room
- Flexible Modes: Supports 1-to-N splitter mode and N-to-1 switch mode
Before You Start
For best performance:
- Maintain clear line of sight between TX and RX when possible
- Avoid obstacles like concrete walls, metal, or thick glass (these reduce range)
- Ensure your source device is set to PCM/LPCM audio if you experience audio issues
Step-by-Step Setup Guide
Step 1: Connect the Transmitter (TX)
- Connect your source device (PC, Blu-ray player, streaming box) to the HDMI IN port on the transmitter
- (Optional) Connect a local display to the HDMI OUT (loop-out) port
- Plug in the power adapter
Once powered, the indicator light will turn on
Step 2: Connect the Receiver (RX)
- Connect the HDMI OUT on the receiver to your TV or projector
- Plug in the power adapter
The receiver will automatically power on and begin initializing
Step 3: Pair the Transmitter and Receiver
Before use, the TX and RX must be paired:
- Connect TX and RX temporarily using an HDMI cable
- Wait for the pairing indicator to stop flashing
- Disconnect the HDMI cable once pairing is complete
If needed, you can reset pairing by holding the reset button for 6+ seconds
Choosing the Right Mode
Splitter Mode (1 TX → Multiple RX)
Use this when sending one source to multiple displays:
- Set both TX and RX to SP mode
- Pair all receivers with the transmitter
- Recommended: Up to 4 receivers for best performance
Switch Mode (Multiple TX → 1 RX)
Use this when switching between multiple sources:
- Set all units to SW mode
- Assign matching ID values between TX and RX
- Only one transmitter connects at a time
Audio Setup Options
This extender gives you flexibility with audio:
- Embed external audio: Use the AUX IN on TX
- Extract audio: Use the AUX OUT on RX for speakers or sound systems
- Supports standard PCM/LPCM audio formats
IR Remote Control Setup
Control your source device remotely:
- Connect IR TX cable to the transmitter and point it at your source
- Connect IR RX cable to the receiver
- Use your remote from the receiver side
Range: up to ~5 meters from IR receiver
Performance Tips
- The system uses 5GHz wireless (802.11ac) for stable transmission
- Latency is less than 80ms, suitable for most AV applications
- Devices automatically select the least congested channel
- Supports multiple systems in the same environment
Common Troubleshooting
No Signal?
- Ensure TX and RX are paired
- Confirm both units are in the same mode (SP or SW)
Poor Signal or Dropouts?
- Reduce obstacles between units
- Adjust antenna angles
- Move away from heavy Wi-Fi interference
No Audio?
- Set source audio output to PCM/LPCM
- Check AUX connections
Ideal Use Cases
- Home theater wireless setups
- Conference rooms and meeting spaces
- Digital signage installations
- Retail and commercial AV distribution
The JTD-3276 Wireless HDMI Extender is a powerful solution for clean, cable-free AV distribution. With support for 4K@30Hz, flexible routing modes, and audio integration, it’s designed to handle both simple and advanced setups with ease.
