Model: JTECH-ENCH4AP

JTD-ID: JTD-3200

Category: Livestream Encoder

Streaming high-quality video over IP is now essential across AV installations, live events, houses of worship, and corporate environments. The 1080P 60Hz H.264 IPTV Livestream Encoder with Audio Embedding and PoE (JTD-3219 / JTECH-ENCH4AP) delivers a powerful, flexible solution for encoding HDMI video into IP streams.

This guide covers what’s in the box, setup, configuration, streaming, and troubleshooting to help you deploy quickly and efficiently.

What is an IPTV Encoder?

An IPTV encoder converts HDMI video into IP-based streams that can be distributed over a network or streamed online.

This encoder supports:

• H.264 / H.265 / MJPEG compression
• RTSP, RTMP, HTTP, UDP, ONVIF protocols
• Multi-platform streaming (YouTube, Facebook, etc.)

It supports 1080p@60Hz input with multiple streaming protocols and remote web GUI control

Key Features (Why Integrators Use This)

Multi-Protocol Streaming Flexibility

Stream to virtually any platform or system:

• RTMP / RTMPS (YouTube, Facebook Live)
• RTSP / UDP / HTTP (local network streaming)
• ONVIF (NVR integration)

HDMI + Analog Audio Embedding

• HDMI video input
• 3.5mm audio input for external mixers
• Embed audio directly into the stream

Perfect for:

• Churches
• Live events
• Conference AV systems

1080p60 Multi-Stream Output

• 1 main stream + 3 substreams
• Stream to multiple platforms simultaneously
• Optimize bandwidth and resolution per destination

Custom Branding with OSD

• Add logos and text overlays
• Custom “No Signal” screen
• Professional broadcast look

PoE (Power Over Ethernet)

• One cable for power + data
• Clean rack installs
• Works with PoE network switches

What’s in the Box

The package includes:

• 1× IPTV Encoder (JTECH-ENCH4AP)
• 1× 12V Power Adapter
• 1× User Manual

What You Need for Setup

Before installation, make sure you have:

• HDMI source (camera, PC, media player)
• Ethernet network (PoE switch recommended)
• Computer for configuration
• Streaming platform (YouTube, Facebook, VLC, etc.)
• Optional: analog audio source (mixer, mic system)

Hardware Overview

Ports include:

• HDMI input
• 3.5mm audio input
• LAN (PoE) port
• Reset button
• Power input (optional if not using PoE)

Step-by-Step Setup Guide

Step 1: Connect Your Source

• Plug HDMI source into encoder
• Optional: connect 3.5mm audio input

Step 2: Connect Network (PoE Recommended)

• Connect LAN port to PoE switch
• Device powers on automatically

(Default IP: 192.168.1.168)

Step 3: Configure Your PC Network

Set your PC to:

• IP: 192.168.1.11
• Subnet: 255.255.255.0

Step 4: Access Web GUI

• Open browser
• Enter: 192.168.1.168
• Login:
  • Username: admin
  • Password: admin

Step 5: Configure Video Stream

Go to:

• Encoder → Main Stream
• Set:
  • Resolution (1080p60)
  • Bitrate
  • Codec (H.264 / H.265)
• Click Apply

Step 6: Configure Audio

Go to:

• Encoder → Audio

Choose:

• HDMI audio
  OR
• Analog (3.5mm input)

Step 7: Get Your Stream URL

• Go to Main Stream section
• Copy stream URL

Use in:

• VLC
• NVR
• Streaming platforms

Step 8: Stream to Platform (RTMP Example)

For YouTube:

• Combine:
  • Server URL + Stream Key
• Paste into RTMP Publish URL
• Apply + reboot

Example Applications

From the application diagram (page 7), this encoder is used for:

• Live streaming to IPTV systems
• Network TV distribution
• Content servers
• Remote viewing over LAN/WAN

Advanced Use Cases

Multi-User Streaming (Multicast)

• Enable multicast in settings
• Multiple users can view same stream simultaneously

NVR / Surveillance Integration

• Enable RTSP + ONVIF
• Add encoder as IP camera

VLC Playback

• Open VLC → “Open Network Stream”
• Paste stream URL

Troubleshooting Guide

Cannot Access Web GUI

• Confirm PC is on same subnet
• Verify IP address
• Check Ethernet connection

No Video Stream

• Confirm HDMI input signal
• Check encoding settings
• Ensure stream protocol is enabled

No Audio

• Verify audio input selection (HDMI vs analog)
• Check audio source levels

Streaming Not Working (RTMP)

• Confirm stream key and URL
• Use Google DNS (8.8.8.8 / 8.8.4.4)
• Check platform stream health

Device Not Powering On

• Confirm PoE switch supports required power
• Use included power adapter if needed

Best Practices for AV Installers

• Use PoE switches for cleaner installs
• Set static IPs for reliability
• Optimize bitrate based on bandwidth
• Use multicast for large internal networks
• Always test stream locally before going live

Why This Encoder Matters

This encoder is ideal for:

• AV integrators
• Houses of worship
• Corporate streaming
• Education & training systems
• Broadcast and IPTV environments

It combines:

• High-quality encoding
• Flexible protocols
• Easy deployment
• Professional branding tools

The 1080P H.264 IPTV Encoder with Audio and PoE is a versatile, professional-grade solution for streaming and AV distribution. With support for multiple protocols, audio embedding, PoE, and multi-platform streaming, it simplifies even complex streaming setups.

If you're building modern AV systems, this encoder delivers reliability, flexibility, and scalability.
